WATER SPECIALIST CONTROL VALVE

Service flow 106 lpm (6.36 m3/h) (28 gpm), backwash flow 57 lpm (3.40 m3/h) (15 gpm) with meter and
bypass installed
Solid state microprocessor with easy access front panel settings
Front panel display for time of day, days until next regeneration, volume remaining, current flow rate and total
volume used (Totalizer), and Tank in Service Indication
Four methods to initiate regeneration; meter immediate, meter delayed, time clock delayed or pressure
differential
Optional double backwash feature offers optimum regeneration, cleaning ability and efficiency
Fully adjustable cycle times with 6-cycle control delivers controlled backwash, downflow brining/slow rinse,
second backwash, fast rinse, refill and downflow service
Coin Cell Lithium battery back-up with a 8 hour carry over
ackwash and brining ability to 21” diameter tanks
Downflow or upflow brining regeneration
12-volt output AC Adapter provides safe and easy installation
Treated/Soft water post fill and regeneration cycles
Patented one piece expanding seal spacer stack assembly U.S. Patent 6,402,944
Patented linearly reciprocating piston operation U.S. Patent 6,444,127
Reliable and proven DC drives
